Laser cutting machine K1325
Specifications:
1) Lathe bed structure ensures the stable operation while carving and cutting at high speed
2) Beam is drawn out of high hardness alloy aluminum material and driven by a large power subdivision server-motor
3) Laser unit served by special radiator and protected without water makes it stable and safe with a longer life span
4) It matches accessories such as rotation platforms, double loser units
5) Operation handle can be chosen
Parameter:
| Model |
K1325 laser engraving machine |
| Engraving Area |
1300×2500mm |
| Engraving Speed |
0-64000mm/min |
| Laser power |
150w |
| Natural life of laser |
10000hours |
| Laser wave length |
10.6um |
| Resolution ratio |
0.025mm |
| Minimum shaping character |
Chinese character 2mm/ letter 1mm |
| Resetting positioning accuracy |
±0.01mm |
| Power Supply |
Ac220v±10%,50HZ |
| Gross Power |
2600w |
| Operating Temperature |
0-45 |
| Operating humidity |
5%-95% |
| Graphic Format Supported |
BMP,GIF,JPEG,PCX,TGA,TIFF,PLT,CDR,DWG,DXF |
| Driver Type |
Stepper Motor |
| Cooling |
air and water cooling |
| Opearate System |
Win98/Win2000/WinXP |
| Max Cutting thickness |
10-30mm(acrylic) |
| Net Weight |
420KG |
| Dimension |
2800×2000×2200mm |
Applicable Matericals
Wood,paper,leather,cloth,organic glass,resin,acrylic,wollens,plastic,rubber,ceramic,tile,crystal,bowlder,bamboo,non-metal etc
Applicable Industry
Cloth embroide fabric toy,fabricture,glove,bag,leather,advertising,decoration,electric product,rubber,acrylic product,middle density,board etc non-metal sheet precision cutting &engraving.
Feature Description:
(1)The software can support AutoCAD/CorelDRAW/CAD/CDR and other graphical software
(2)The USB interface can support heat play & pluy
(3)Quick data transitting
(4)Chinese&English edition liquid display can make it easy for user to operate
Optional Accessory Pictures:
